- Size:13.3 inch
- Resolution:2560×1440
- Panel Interface:40 pins eDP (4 Lanes)
- Active Area:293.76*165.24 (H×V)mm
- Outline Dimension:340.3*190.1(H×V)mm
- Viewing Angle:80/80/80/80 (Min.)(CR≥10)
- Operation / Storage Temp:0~50°C / -20~60°C
13.3 Inch 2560×1440 2K Resolution LCD Panel EDP 40 Pins Interface IPS LCD Display for Laptop
$110.00
13.3″ IPS 2K LCD — 2560×1440 | Wide Color Gamut | eDP
13.3-inch 2K QHD IPS panel with wide color gamut and broad controller board compatibility. Delivers noticeably sharper imagery than standard FHD panels, making it a strong choice for portable monitor builds, laptop replacements, and embedded displays where higher resolution and color accuracy are priorities.
| General Features | |||
| Screen Size | 13.3 inch | Type | LCM , IGZO TFT-LCD |
| Resolution | 2560(RGB)*1440 (Quad-HD) | Configuration | RGB Vertical Stripe |
| Active Area(mm) | 293.76*165.24 (H×V)mm | Outline(mm) | 340.3*190.1(H×V)mm |
| Bezel Area(mm) | – | Treatment | Antiglare |
| Luminance | – | Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry | Response Time | 25 (Typ.)(Tr+Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) | Operating Mode | AHVA, Normally White, Transflective |
| Support Color | 16.7M 72% (CIE1931) | Backlight | WLED , |
| Shape Style | Slim (PCBA Flat) | Used for | laptop |
| Refresh Rate | 60Hz | Touchscreen | optional |
| Voltage Supply | 3.3V (Typ.) | Signal Type | – |
| Environment | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C | ||
Features:
- 2560×1440 Quad-HD Resolution — Significantly sharper than standard FHD panels. Text, icons, and images are noticeably crisper. Ideal for productivity, design work, and high-resolution content.
- IPS Wide Viewing Angle — Accurate color reproduction across wide horizontal and vertical angles. No shift or washout at off-axis positions. Suitable for shared-viewing and portable use scenarios.
- 1000:1 Contrast Ratio — Clear distinction between light and dark content. Sharp text and graphic rendering. Good depth for media and image display.
- WLED Backlight — Energy-efficient and long-lasting. Uniform illumination across the full panel. Reduces operational costs in always-on builds.
Ideal for: 2K portable monitor builds · Laptop QHD screen replacement · High-resolution embedded monitors · Creative workstation secondary displays · Professional design & photography review panels
Wisecoco offers One-step customized LCD display solutions.
