- Size:7.8 inch
- Resolution:800×300
- Panel Interface:LVDS
- Active Area:184.8×69.3 (H×V)mm
- Outline Dimension:207×86(H×V)mm
- Viewing Angle :IPS
- Brightness(cd/m2):500nits
- Operation / Storage Temp:-30~80°C / -30~80°C
$85.00
|
Diagonal Size
|
7.8 inch
|
Type
|
LCM, a-Si TFT-LCD
|
|
Pixel Format
|
800(RGB)×300
|
Configuration
|
RGB Vertical Stripe
|
|
Active Area
|
184.8×69.3 (H×V)mm
|
Outline Dim.
|
207×86(H×V×D)mm
|
|
Bezel Area
|
Treatment
|
Antiglare, Hard coating (3H)
|
|
|
Luminance
|
500 cd/m² (Typ.)
|
Contrast Ratio
|
1000:1 (Typ.) (TM)
|
|
View Direction
|
Symmetry
|
Response Time
|
12/12 (Typ.)(Tr/Td) ms
|
|
Viewing Angle
|
85/85/85/85 (Typ.)(CR≥10)
|
Operating Mode
|
SWV, Normally Black, Transmissive
|
|
Support Color
|
262K/16.7M 72% (CIE1931)
|
Light Source
|
WLED , 100K hours , With LED Driver
|
|
Weight
|
200g (Typ.)
|
Designed For
|
industrial,automotive display
|
|
Frame Rate
|
60Hz
|
Touch Panel
|
Available
|
|
Interface Type
|
LVDS (1 ch, 6/8-bit)
|
||
|
Power Supply
|
12.0V (Typ.)
|
||
|
Environment
|
Storage Temp.: -30 ~ 80 °C Operating Temp.: -30 ~ 80 °C
|
||
7.8 Inch Stretched Bar LCD Display with 800*300 resolutions 16.7M color depth,the display could let you see a clear world.With 500cd/m2 High luminance and 1000:1 high contarst ra tio,low reflection and wide viewing angle,the display could make you see the real image even under the sun.Model be applied to Automotive Display ,Industrial display etc.
