- Size:10.1 inch
- Resolution:2560×1600
- Interface:eDP(4 Lanes)
- Active Area:216.576(W)×135.36(H) mm
- Outline Dimension:232.22(W)×156.92(H) ×5.2(D) mm
- Viewing Angle :89/89/89/89 (Typ.)(CR≥10)
- High Brightness :370 cd/m2 (TYP)
- Operation / Storage Temp:0~50°C / -20~60°C
10.1 Inch 2560×1600 2K Ips Tft LCD Display Screen EDP LCD Module for Medical Equipments
$95.00
10.1″ 2K TFT-LCD Display — 2560×1600 WQXGA | 370 cd/m² | Viewing Angle | eDP
10.1-inch a-Si TFT-LCD features 2560×1600 WQXGA resolution and a PLS, normally black, transmissive display mode for detailed visual output. With 370 cd/m² typical luminance, 89/89/89/89 viewing angles, 60Hz operation, and a 4-lane eDP interface, it is designed for laptop and computer applications.
|
Screen Size
|
10.1 inch
|
Type
|
a-Si TFT-LCD , LCM
|
|
Resolution
|
2560(RG/BW)×1600 , WQXGA
|
Pixel Format
|
RG/BW LCD PenTile
|
|
Display Area
|
216.576(W)×135.36(H) mm
|
Bezel Opening
|
–
|
|
Outline Size
|
232.22(W)×156.92(H) ×5.2(D) mm
|
Surface
|
Glare (Haze 0%), Hard coating (2H)
|
|
Luminance
|
370 cd/m2 (Typ.)
|
Contrast Ratio
|
800:1 (Typ.) (TM)
|
|
Best View on
|
Symmetry
|
Response Time
|
16 (Typ.)(Tr+Td)
|
|
Viewing Angle
|
89/89/89/89 (Typ.)(CR≥10)
|
Display Mode
|
PLS, Normally Black, Transmissive
|
|
Display Colors
|
16.2M 70% (CIE1931)
|
Lamp Type
|
7S6P WLED , 12K hours , With LED Driver
|
|
Frequency
|
60HZ
|
Transmissivity
|
–
|
|
Signal Interface
|
Edp(4 Lanes), 40 pins, Connector
|
Touch screen
|
Without
|
|
Input Voltage
|
3.3V (Typ.)
|
Application
|
Laptop, computer
|
|
Environment
|
Operating Temp.: 0~ 50 °C ; Storage Temp.: -20 ~ 60 °C
|
||
Features:
- 2560×1600 WQXGA Resolution — Provides high pixel density and detailed visual content for laptop and computer displays.
- PLS Display Technology — Uses a normally black, transmissive display mode for clear graphical content.
- 370 cd/m² Typical Luminance — Provides practical display brightness for the specified laptop and computer applications.
- 89/89/89/89 Wide Viewing Angle — Supports consistent viewing performance from different directions.
- 60Hz Refresh Rate — Provides standard refresh performance for everyday computer and laptop interfaces.
Ideal for: Laptops · Computers · Portable Computing Devices · Embedded Computer Displays
Contact Wisecoco for One-step LCD panel solutions.
