- Size:7 inch
- Resolution:1024×600
- Panel Interface:FPC , 50 pins
- Active Area:154.08×85.92 mm (HxV)
- Outline Dimension:164.9x100x6 mm (HxVxD)
- Viewing Angle :70/70/50/70 (Typ.)(CR≥10)
- Brightness :400 cd/m² (Typ.)
- Touch Panel:I2C Touch
- Operation / Storage Temp:-30~85°C / -30~85°C
-18%
Wisecoco Sunlight Readable 7 Inch 1024*600 Wide Temperature High Brightness 1000nits Lvds I2c Touchscreen Lcd Module Display
Original price was: $56.00.$46.00Current price is: $46.00.
7″ IPS TFT LCD Module — 1024×600 | LVDS 40Pins | WLED Backlight
7-inch IPS TFT-LCD display module delivering 1024×600 resolution with symmetrical wide viewing angle (85/85/85/85) and a standard LVDS 40-pin interface. Featuring U/D/L/R reverse configuration and WLED backlight, this industrial-grade display panel module offers customizable brightness for flexible integration.
|
Type
|
IPS
|
|
Display Size
|
7 inch
|
|
Place of Origin
|
Guangdong,China
|
|
Brand Name
|
wisecoco
|
|
Resolution
|
1024*600
|
|
Type
|
IPS TFT
|
|
Interface
|
LVDS 40Pins
|
|
Product Name
|
Display Screen Panel Module
|
|
Application
|
Industrial
|
|
Brightness
|
customized
|
|
Viewing Angle
|
85/85/85/85
|
|
Operating Temperature
|
-20~+70°C
|
|
Display Area
|
152.4*91.44 mm
|
|
Outter dimension
|
167.7*109.45*9 mm
|
Features:
- 1024×600 Resolution — Clear, sharp imagery for icons, UI graphics, and video content.
- IPS Wide Viewing Angle (85/85/85/85) — Consistent color and brightness maintained from virtually any angle, avoiding shift and contrast loss.
- U/D/L/R Reverse Configuration — Flexible display orientation to fit diverse mounting and device designs.
- WLED Backlight — Efficient, reliable illumination for consistent visibility.
- Customizable Brightness — Brightness level tailored to specific project and application requirements.
Ideal for: Industrial control panels · Equipment status display modules · Embedded HMI applications · Machine interface panels · Custom industrial product integration
Wisecoco offers One-step customized display module solutions.
