- Size:1.39 inch
- Resolution:400×400
- Panel Interface:MIPI
- Outline Dimension:38.6(H)x40.5(V)x0.7(T) mm (Typ.)
- Active Area:35.4 x35.4 mm
- Viewing Angle :80/80/80/80 (Min.)(CR≥1600)
- Brightness(cd/m2):300cd/m²(Typ.)
- Contrast Ratio:10000:1 (Typ.)
-19%
Small 400*400 Round Circular 1.39 Inch Small Flexible Circular Oled Display 1.39″ AMOLED Screen For Robot Eyes
Original price was: $110.00.$89.00Current price is: $89.00.
| General Features | |||
| Panel Size | 1.39 inch | Panel Type | AM-OLED , OLED |
| Resolution | 400(RGB)*400 | Pixel Format | RGB Vertical Stripe |
| Display Area |
35.4(W)*35.4(H) mm
|
Bezel Opening | – |
| Outline Size | 40.5(W)*38.6(H)*0.79(D) mm | Surface |
Glare (Haze 0%), Hard coating (3H)
|
| Brightness |
350 Cd/m² (Typ.)
|
Contrast Ratio | 10000:1 (Min.) (TM) |
| Viewing angle | 80/80/80/80 (Min.)(CR≥1600) | Display Mode | – |
| Best View on | Symmetry | Response Time | 2/2 (Typ.)(Tr/Td) |
| Display Colors | 16.7M 100% (CIE1931) | Lamp Type | Self |
| Frequency | – | Touch Screen | Without |
| Panel Weight | 2.15±0.33g | Application | Oled watch display |
| Signal Interface |
MIPI (1 data lane) , 24 pins , Connector
|
||
| Input Voltage | 1.8/2.8/4.6/-2.4V (Typ.)(VDDIO/VCI/ELVDD/ELVSS) | ||
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C | ||
This module has a diameter of 1.39 inches and a resolution of 400×400, capable of displaying vibrant images with 16.7 million colors and a brightness of up to 300 nits. It enables efficient data transmission via a MIPI interface. It is a high-performance circular flexible AMOLED display designed specifically for high-end wearable devices and small-form-factor devices.
Available Applications:Smart Watch/Portable instrument /Digital camera monitor/Smart home device
High quality!
Large Stock!
Cost-Effective!
Long-term supply!
Welcome to contact us and get our best service!
| Color | Brown, Green |
|---|
