Industrial 4.3 Inch 800x480 TFT LCD Display Touch Screen
4.3 inch 800x480 lcd display
4.3 inch 800x480 lcd display
4.3 inch 800x480 lcd display
4.3 inch 800x480 lcd display
4.3 inch 800x480 lcd display

Industrial 4.3 Inch Resolution 800*480 Pixels 24 Bit RGB Interface Touch Screen TFT LCD I2C Touch Screen Display Panel Module

Original price was: $49.00.Current price is: $20.00.

  • Size:4.3 inch
  • Resolution:800×480
  • Panel Interface:24-bit RGB interface
  • Active Area:95.04(W)x53.86(H) mm
  • Outline Dimension:105.40(W)x67.10(H)x4.65(T) mm
  • Brightness :300 Cd/m^2 (Typ.)
  • Touch Panel:I2C Touch
  • Operation / Storage Temp:-20~70°C / -30~80°C

>Get a Quote

4.3″ TFT-LCD Display — 800×480 | 24-Bit RGB Interface | Handheld & Industrial Grade

4.3-inch TFT-LCD display delivering 800(RGB)×480 resolution with reliable 300cd/m² brightness and a 24-bit RGB interface. Featuring optional touchscreen with I2C interface, wide temperature tolerance, and a compact form factor, this display is purpose-built for handheld PDAs, industrial equipment, and time recording devices.

General Features
Screen Size 4.3 inch Type TFT-LCD
Resolution 800(RGB)x480 Configuration RGB Vertical Stripe
Active Area(mm) 95.04(W)x53.86(H) mm Outline(mm) 105.40(W)x67.10(H)x4.65(T) mm
Bezel Area(mm) – Treatment –
Luminance 300 cd/m2 (Typ.) Contrast Ratio 300:1
View Direction 6 o’clock Response Time –
Viewing Angle – Operating Mode Transmissive Type, Normally White Mode
Support Color 16.7M   50% NTSC Backlight Voltage 22.4V(Typ.), Current 20mA(Typ.)
Panel Weight – Used for Handheld&PDA, Industrial Equipment, Time Recording
Refresh Rate – Touchscreen optional
Voltage Supply – Signal Type 24-bit RGB interface (LCD), I2C interface (CTP)
Environment Storage Temp.: -30 ~ 80 °C    Operating Temp.: -20 ~ 70 °C

Features:

  • 800×480 Resolution — Clear, sharp imagery for icons, text, and video content.
  • 24-Bit RGB Interface — Rich, straightforward parallel connectivity for reliable integration with embedded systems.
  • 16.7M Colors, 50% NTSC — Rich color reproduction for accurate, vivid visuals.
  • Optional Touchscreen with I2C Interface — Touch functionality available with a straightforward capacitive touch panel controller interface.
  • Wide Operating Temperature Range — Operating -20~70°C, storage -30~80°C, reliable across demanding environments.

Ideal for: Handheld & PDA devices · Industrial equipment displays · Time recording & attendance systems · Portable instrument screens · Custom embedded HMI applications

Wisecoco offers One-step customized display module solutions.
