5 inch AMOLED Display H497TLB01.0 IPS 5 inch 720P OLED Display HD 720*1280 Screen Panel

Original price was: $97.00.Current price is: $78.00.

Contact us to learn better prices

General Features

Diagonal Size

5.0 inch

Type

AM-OLED, OLED

Pixel Format

720(RGB)×1280  [WXGA]  295PPI

Configuration

RGB Vertical Stripe

Active Area

61.92(H)×110.08(V) mm

Outline Dim.

65.92(H)×118.64(V) ×1.15(D) mm

Luminance

250 cd/m² (Typ.)

Contrast Ratio

10000:1 (Min.) (TM)

View Direction

Symmetry

Response Time

1.0 (Max.)

Viewing Angle

80/80/80/80 (Min.)(CR≥1600)

Operating

Support Color

16.7M   100% NTSC

Light Source

self

Weight

TBD

Designed For

Mobile phone, Medical equipments.

Frame Rate

60Hz

Touch Panel

On-Cell Touch

Interface Type

 MIPI (4 data lanes) , 39 pins FPC

Power Supply

1.8/3.1/3.7V (Typ.)(VDDI/VCI/VBAT)

Environment

Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C

Color

White
